Remplacement de la batterie
Share
Required tools
- Small Phillips screwdriver
- A new battery (provided by Fabli)
- Small container to hold screws and other small parts removed
Instructions
1. Using a small Phillips screwdriver, unscrew all the screws on the back of the Fabli.
2. Place the Fabli face-down on a table (buttons facing downward) and remove the back part of the shell.
3. Remove the yellow side buttons from the Fabli (blue circle)
4. Then remove the battery connector (green circle) by pulling on the top part of the connector which is directly connected to the battery cables.
5. Peel the old battery from its holder.
6. Remove the adhesive strip from the new battery.
7. Place the battery with the adhesive strip on the support side, ensuring that the bottom of the battery is in contact with the end of the support.
8. Replace the battery by positioning the bracket's tabs over the small protrusions that pass through the circuit board and reconnect the battery connector.
9 . Put the buttons back in place as shown.
10. Time to close the shell! Make sure the top of the WiFi/Bluetooth switch fits into its slot and align the back shell with the front before closing it. The shell edges should snap together without resistance.
If it doesn't close easily, reopen and check that nothing is blocking it—especially that the speaker cable runs between the switch and the speaker, not directly over it (see step 4).
11. Screw the back shell screws back in—and that's it! The repair is complete!
WARNING: Never open or attempt to repair your Fabli without clear instructions from our team. Unauthorized repairs will automatically void the warranty.
